| 規格 | 比重 | 進出口徑 mm | 馬力 | 50Hz | 60Hz | 重量kg | ||||||
| 相數 | HP | 極數 | 曲線 | 全揚程 M | 全流量 L/min | 曲線 | 全揚程 M | 全流量 L/min | ||||
| TDD-40SK-1 | 1.1 | 50X40 | 3? | 1 | 2 | a | 14 | 280 | A | 13 | 250 | 29 |
| TDD-40SK-2 | 1.1 | 50X40 | 3? | 2 | 2 | b | 18 | 400 | B | 22 | 320 | 38 |
| TDD-40SK-3 | 1.1 | 50X40 | 3? | 3 | 2 | c | 22 | 450 | C | 26 | 420 | 41 |
| TDD-50SK-3 | 1.1 | 65X50 | 3? | 3 | 2 | d | 21 | 530 | D | 23 | 520 | 41 |
| TDD/STDD-50SK-5 | 1.1 | 65X50 | 3? | 5 | 2 | e | 31 | 580 | E | 36 | 560 | 55 |
| TDD/STDD-65SK-5 | 1.1 | 80X65 | 3? | 5 | 2 | f | 29 | 550 | F | 29 | 700 | 55 |
| TDD/STDD-65SK-7.5 | 1.1 | 80X65 | 3? | 7.5 | 2 | g | 34 | 730 | G | 37 | 960 | 95 |
| TDD/STDD-65SK-10 | 1.1 | 80X65 | 3? | 10 | 2 | h | 37 | 760 | H | 39.5 | 1100 | 106 |
| TDD-40SP-3 | 1.4 | 50X40 | 3? | 3 | 2 | i | 22 | 400 | I | 23 | 340 | 41 |
| TDD-50SP-3 | 1.4 | 65X50 | 3? | 3 | 2 | j | 19 | 500 | J | 19 | 400 | 41 |
| TDD/STDD-50SP-5 | 1.4 | 65X50 | 3? | 5 | 2 | k | 28 | 560 | K | 32 | 500 | 55 |
| TDD/STDD-65SP-5 | 1.4 | 80X65 | 3? | 5 | 2 | l | 27 | 520 | L | 25 | 600 | 55 |
| TDD/STDD-65SP-7.5 | 1.4 | 80X65 | 3? | 7.5 | 2 | m | 31 | 720 | M | 35 | 750 | 95 |
| TDD/STDD-65SP-10 | 1.4 | 80X65 | 3? | 10 | 2 | n | 33 | 750 | N | 38 | 850 | 106 |
