| 規(guī)格 | 比重 | 進出口徑 mm | 馬力 | 50Hz | 60Hz | 重量 kg | ||||||
| 相數(shù) | HP | 極數(shù) | 曲線 | 全揚程 M | 全流量 L/min | 曲線 | 全揚程 M | 全流量 L/min | ||||
| TD-40SK-1 | 1.1 | 50×40 | 3? | 1 | 2 | a | 11.5 | 250 | A | 13 | 250 | 29 |
| TD-40SK-2 | 1.1 | 50X40 | 3? | 2 | 2 | b | 15 | 325 | B | 22 | 320 | 38 |
| TD-40SK-3 | 1.1 | 50X40 | 3? | 3 | 2 | c | 18 | 365 | C | 26 | 420 | 41 |
| TD-50SK-3 | 1.1 | 65X50 | 3? | 3 | 2 | d | 18 | 620 | D | 23 | 520 | 41 |
| TD/STD-50SK-5 | 1.1 | 65X50 | 3? | 5 | 2 | e | 26.5 | 735 | E | 36 | 560 | 55 |
| TD/STD-65SK-5 | 1.1 | 80X65 | 3? | 5 | 2 | f | 23 | 885 | F | 29 | 700 | 55 |
| TD/STD-65SK-7.5 | 1.1 | 80X65 | 3? | 7.5 | 2 | g | 26.5 | 995 | G | 37 | 960 | 95 |
| TD/STD-65SK-10 | 1.1 | 80X65 | 3? | 10 | 2 | h | 30 | 1100 | H | 39.5 | 1100 | 106 |
| TD-40SP-3 | 1.4 | 50X40 | 3? | 3 | 2 | i | 19.5 | 475 | I | 23 | 340 | 41 |
| TD-50SP-3 | 1.4 | 65X50 | 3? | 3 | 2 | j | 19 | 500 | J | 19 | 400 | 41 |
| TD/STD-50SP-5 | 1.4 | 65X50 | 3? | 5 | 2 | k | 28 | 560 | K | 32 | 500 | 55 |
| TD/STD-65SP-5 | 1.4 | 80X65 | 3? | 5 | 2 | l | 18.5 | 715 | L | 25 | 600 | 55 |
| TD/STD-65SP-7.5 | 1.4 | 80X65 | 3? | 7.5 | 2 | m | 21 | 885 | M | 35 | 750 | 95 |
| TD/STD-65SP-10 | 1.4 | 80X65 | 3? | 10 | 2 | s | 26 | 995 | S | 38 | 850 | 106 |
| TD-50SL-1 | 1.4 | 50X50 | 3? | 1 | 4 | q | 6 | 320 | Q | 8.5 | 400 | 30 |
| TD-80SL-2 | 1.4 | 80X80 | 3? | 2 | 4 | r | 9 | 400 | R | 13 | 480 | 40 |
| TD-80SK-5 | 1.1 | 80X80 | 3? | 5 | 2 | u | 24.5 | 950 | 黃色部份為大流量規(guī)格 | |||
| TD-80SK-7.5 | 1.1 | 80X80 | 3? | 7.5 | 2 | t | 26.5 | 1065 | ||||
| TD-80SK-10 | 1.1 | 80X80 | 3? | 10 | 2 | w | 32 | 1140 | ||||
| TD-100SK-10 | 1.1 | 100x100 | 3? | 10 | 2 | o | 26.5 | 1235 | O | 31 | 1200 | 102 |
| TD-100SK-15 | 1.1 | 100x100 | 3? | 15 | 2 | p | 26.5 | 1455 | P | 35 | 1950 | 114 |
| TD-125SK-15 | 125X125 | 15 | 2 | |||||||||
