| 型 式 | 1004 | 2004 | 2006-1 | 2008-1 | 2008-2 | 2012-2 | 2018-3 | 2018-3 | |
| 適合過濾量Capacity (l/min以內(nèi)) | 60 | 80 | 150 | 180 | 220 | 220 | 330 | 450~500 | |
| 濾 材Filtration method | 濾心式 | 10"X4 | 20"X4 | 20" X 6 | 20" X8 | 20" X 8 | 20" X 12 | 20" X 18 | 20" X 18 |
| 楊桃濾袋式 | 1Set(36pcs) | 1Set(36pcs) | 1Set(36pcs) | 1Set(48pcs) | 1Set(56pcs) | 1Set(56pcs) | |||
| 濾紙式 | 124Φ x 28 | 124Φ x 53 | 198Φ x 46 | 234Φ x 44 | 234Φ x 44 | 302Φ x 40 | 370Φ x 38 | 370Φ x 38 | |
| 溫度范圍 (℃)Max. Temperature | 65 | 65 | 65 | 65 | 65 | 65 | 65 | 65 | |
| 濾筒外徑 | 200 | 200 | 280 | 315 | 315 | 400 | 450 | 450 | |
| 泵浦馬達(HP) Power | 1/4~1/3 | 1/3 | 1 | 1 | 2 | 2 | 3 | 3 | |
| 外型尺寸Dimensions (mm) | 長度 (A) Length | 500 | 570 | 730 | 730 | 730 | 810 | 810 | 810 |
| 寬度 (B) Width | 355 | 355 | 420 | 445 | 445 | 530 | 570 | 570 | |
| 高度 (C) Height | 910 | 1170 | 1500 | 1500 | 1500 | 1560 | 1580 | 1580 | |
| 出入口徑（吋）Fitting | 1" | 1" | 1-1/2" | 1-1/2" | 1-1/2" | 1-1/2" | 2" | 2-1/2" | |
| 機體重量 (kg) Weight (含泵浦2HP) | 28 | 32 | 73 | 76 | 80 | 106 | 125 | 125 | |
