Model 規格 |
S.G. 比重 |
In/Outlet 進出口徑 mm |
Power 馬力 | 50Hz | 60Hz |
Weight 重量 Kg |
||||||
|
Phase 相數 |
HP |
Pole 極數 |
Curve 曲線 |
Max.Head 全揚程M |
Max.Flow 全流量 L/min |
Curve 曲線 |
Max.Head 全揚程M |
Max.Flow 全流量 L/min |
||||
| 40SK-1 | 1.1 | 40X40 | 1?/3? | 1 | 2 | b | 10 | 310 | B | 10 | 300 | 29 |
| 40SK-2 | 1.1 | 40X40 | 3? | 2 | 2 | c | 14.5 | 350 | C | 17.5 | 350 | 32 |
| 50SK-3 | 1.1 | 50X50 | 3? | 3 | 2 | d | 19.5 | 540 | D | 20.5 | 540 | 56 |
| 50SK-5 | 1.1 | 50X50 | 3? | 5 | 2 | e | 22 | 600 | E | 31 | 580 | 72 |
| 65SK-7.5 | 1.1 | 80X65 | 3? | 7.5 | 2 | f | 22 | 860 | F | 28 | 800 | 116 |
| 65SK-10 | 1.1 | 80X65 | 3? | 10 | 2 | g | 22 | 860 | G | 31 | 1050 | 122 |
| 40SP-1 | 1.4 | 40X40 | 1?/3? | 1 | 2 | h | 9 | 280 | H | 8 | 260 | 29 |
| 40SP-2 | 1.4 | 40X40 | 3? | 2 | 2 | i | 14.5 | 340 | I | 15 | 325 | 32 |
| 50SP-3 | 1.4 | 50X50 | 3? | 3 | 2 | j | 17 | 500 | J | 17 | 500 | 54 |
| 50SP-5 | 1.4 | 50X50 | 3? | 5 | 2 | k | 22 | 600 | K | 23 | 540 | 72 |
| 65SP-7.5 | 1.4 | 80X65 | 3? | 7.5 | 2 | l | 20 | 760 | L | 28 | 800 | 116 |
| 65SP-10 | 1.4 | 80X65 | 3? | 10 | 2 | m | 22 | 920 | M | 31 | 850 | 122 |
| 25SL-1/2 | 1.1 | 25X25 | 1?/3? | 1/2 | 2 | a | 5 | 90 | A | 12.5 | 105 | 26 |
| 40SL-1/2 | 1.4 | 40X40 | 3? | 1/2 | 4 | o | 5 | 190 | O | 6.5 | 240 | 29 |
| 50SL-1 | 1.4 | 50X50 | 3? | 1 , | 4 | p | 5 | 390 | P | 7.5 | 470 | 32 |
| SVT40SK-1/2 | 1.1 | 40X40 | 1?/3? | 1/2 | 2 | n | 9 | 180 | N | 9 | 150 | 24 |
| SVT40SK-1 | 1.1 | 40X40 | 1?/3? | 1 | 2 | b | 10 | 310 | B | 10 | 300 | 27 |
| SVT40SK-2 | 1.1 | 40X40 | 3? | 2 | 2 | c | 14.5 | 350 | C | 17.5 | 350 | 30 |
